Spectrophotometer V1200 Visible Type, 320–1100 nm

The Spectrophotometer V1200 Visible Type, 320–1100 nm is a laboratory analytical instrument designed to measure the absorbance and transmittance of light in suitable liquid samples and prepared solutions. The V1200 Spectrophotometer is widely applicable in chemical analysis, educational laboratories, research facilities, and industrial quality control environments where routine optical measurements are required.

With a specified wavelength range of 320–1100 nm, the V1200 Spectrophotometer supports a wide range of spectrophotometric applications. It features manual wavelength adjustment, a tungsten lamp light source, a silicon photodiode detector, and an LCD display for convenient operation. Its practical design makes it suitable for laboratories looking for a straightforward instrument for routine analytical work.

Key Features of the Spectrophotometer V1200 Visible Type

• Wavelength Range: 320–1100 nm
• Spectral Bandwidth: 4 nm
• Wavelength Accuracy: ±2 nm
• Wavelength Repeatability: 1 nm
• Photometric Accuracy: 0.5%T
• Photometric Repeatability: 0.2%T
• Stray Light: 0.15%T at 500 nm
• Stability: 0.002 A at 500 nm
• Wavelength Setting: Manual
• Light Source: Tungsten lamp
• Detector: Silicon photodiode
• Display: 70 × 40 mm blue-lit LCD
• Output Interface: USB or RS232 port, depending on configuration
• Power Supply: AC 220 V/50 Hz or AC 110 V/60 Hz, depending on model version
• Dimensions: Approximately 420 × 350 × 200 mm
• Net Weight: Approximately 8 kg

Applications of the V1200 Spectrophotometer

1. Chemical Analysis

The V1200 Spectrophotometer can measure the absorbance and transmittance of prepared chemical solutions. With appropriate calibration standards and validated analytical procedures, these measurements can help determine the concentration of selected substances in laboratory samples.

2. Educational and Academic Laboratories

Universities, colleges, and technical institutions can use the Spectrophotometer V1200 Visible Type for practical experiments involving absorbance, transmittance, the Beer–Lambert law, and concentration determination. It can support laboratory teaching and student research activities.

3. Research and Development

Research laboratories can use the V1200 for routine spectrophotometric measurements involving suitable compounds and prepared samples. Its manual wavelength adjustment allows users to select the required wavelength within the instrument’s specified range.

4. Industrial Quality Control

The V1200 Spectrophotometer can support selected quality control procedures, sample comparisons, and product testing when the instrument’s specifications are suitable for the analytical method being used.

5. Water and Environmental Testing

The instrument may be used for selected colorimetric water and environmental testing methods. Reliable results depend on suitable reagents, sample preparation, calibration, and the requirements of the relevant testing procedure.

User-Friendly Operation and Connectivity

The Spectrophotometer V1200 Visible Type features manual wavelength selection and an LCD display to support routine laboratory operation. Its tungsten lamp provides the light source, while the silicon photodiode detector measures the optical response of the sample.

Depending on the supplied configuration, the instrument may include a USB or RS232 interface for communication with compatible external devices. Users should verify software and computer compatibility before purchasing or connecting the instrument.

For consistent measurements, appropriate blank preparation, calibration, sample handling, and routine maintenance should be performed according to the manufacturer’s instructions.

Compact Design for Laboratory Workbenches

With approximate dimensions of 420 × 350 × 200 mm and a net weight of around 8 kg, the V1200 Spectrophotometer offers a compact design for many laboratory workspaces. It can be considered for educational institutions, research laboratories, and routine analytical facilities where bench space is an important consideration.

Why Choose the Spectrophotometer V1200 Visible Type, 320–1100 nm?

The Spectrophotometer V1200 Visible Type, 320–1100 nm combines a broad specified wavelength range with manual wavelength adjustment, a tungsten lamp, a silicon photodiode detector, and a clear LCD display. Its listed measurement specifications and compact construction make it a practical option for laboratories performing suitable routine spectrophotometric analysis.

Before purchasing, users should confirm the required wavelength range, photometric performance, sample compartment compatibility, power supply, output interface, software support, and included accessories.

For laboratory equipment and scientific instruments in Bangladesh, visit M/S Bright Scientific Co. to explore available products and request further information.

Frequently Asked Questions (FAQ)

1. What is the Spectrophotometer V1200 Visible Type used for?

The V1200 is used to measure absorbance and transmittance in suitable samples for chemical analysis, educational experiments, research, and selected quality control applications.

2. What is the wavelength range of the V1200 Spectrophotometer?

The specified wavelength range is 320–1100 nm.

3. What is the spectral bandwidth of the Spectrophotometer V1200?

The specified spectral bandwidth is 4 nm.

4. Which light source does the V1200 use?

The V1200 uses a tungsten lamp as its light source.

5. What type of detector is used in the V1200 Spectrophotometer?

It uses a silicon photodiode detector.

6. Does the Spectrophotometer V1200 support computer connectivity?

The listed specifications include a USB or RS232 interface, depending on the configuration. Confirm compatibility with the intended computer and software.

7. What type of display does the V1200 have?

It features a 70 × 40 mm blue-lit LCD display.

8. What is the power requirement of the V1200 Spectrophotometer?

The listed power options are AC 220 V/50 Hz or AC 110 V/60 Hz, depending on the version. Verify the instrument’s rating label before connecting it to a power supply.

9. Is the V1200 suitable for educational and research laboratories?

Yes. It can support suitable teaching experiments, routine optical measurements, and research applications within its specified performance limits.

10. What are the dimensions and weight of the V1200?

The listed dimensions are approximately 420 × 350 × 200 mm, and its net weight is approximately 8 kg.

Conclusion

The Spectrophotometer V1200 Visible Type, 320–1100 nm is designed for routine laboratory measurements involving absorbance and transmittance. Its specified wavelength range, 4 nm spectral bandwidth, tungsten lamp, silicon photodiode detector, LCD display, and available connectivity options make it a useful choice for suitable chemical analysis, education, research, and quality control workflows. Visit Bright Scientific for laboratory equipment and scientific instruments in Bangladesh.
